Engine Coolant Thermostat Gates 34163S

Engine Coolant Thermostat Gates 34163S

$37.52 - $37.52
$37.52 - $37.52
$37.52
$37.52 - $37.52
$37.52

Part will fit your current fitment selection of None

Part will NOT fit your current fitment selection of None

by Gates
Availability:
in stock, ready to be shipped
 More payment options

Gates Premium Thermostats feature a heavy gauge stainless steel construction for improved corrosion resistance, as well as an upgraded spring for increased temperature stability under normal operation conditions.

Los termostatos Premium de Gates están fabricados en acero inoxidable de gran espesor para mejorar la resistencia a la corrosión, así como con un muelle mejorado para aumentar la estabilidad de la temperatura en condiciones normales de funcionamiento.

Les thermostats Gates Premium sont fabriqués en acier inoxydable de forte épaisseur pour une meilleure résistance à la corrosion, ainsi qu'avec un ressort amélioré pour une meilleure stabilité de la température dans des conditions de fonctionnement normales.

Upgraded thermal valve prevents thermal shock to cooling system components

Specially-formulated wax mixture reacts quickly to changes in coolant temperature

Jiggle pins for air venting, seals and gaskets make these thermostats equivalent to the original equipment part

Well-suited for severe duty and high-performance applications

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

La válvula térmica mejorada evita el choque térmico en los componentes del sistema de refrigeración

La mezcla de cera especialmente formulada reacciona rápidamente a los cambios en la temperatura del refrigerante

Los pasadores para la liberación de aire, las juntas y los retenes hacen que estos termostatos sean equivalentes a las piezas del equipo original.

Ideal para aplicaciones de alto rendimiento

ADVERTENCIA: Cáncer y daños reproductivos - www.P65Warnings.ca.gov

La soupape thermique améliorée empêche les chocs thermiques sur les composants du système de refroidissement.

Le mélange de cire spécialement formulé réagit rapidement aux changements de température du liquide de refroidissement

Des goupilles pour l'évacuation de l'air, des joints et des garnitures d'étanchéité rendent ces thermostats équivalents à la pièce d'origine.

Convient parfaitement aux applications à usage intensif et à haute performance

AVERTISSEMENT: Cancer et méfaits de la reproduction – www.P65Warnings.ca.gov

Premium Engine Coolant Thermostat

Name Value
Length - Each (Inch) 2.7500
Length - Case (Inch) 14.5750
Width - Each (Inch) 2.7500
Width - Case (Inch) 11.3750
Start to Open Temperature (Degrees Fahrenheit) 180
Start to Open Temperature (Degrees Celsius, Centigrade) 82
Design Bottom By-Pass
Height (Inch) 2.54
Sealing Flange Outside Diameter (Inch) 1.61
Height Between Flanges (Inch) 1.7
Jiggle Pin Weep Hole Yes
Seal Type Gasket
Short Description Thermostat
Grade Type OE Improved
Seal Material Paper
Coil Inside Diameter (in) - A .84
Installation Tool Included Yes
Jiggle Pin Check Valve Quantity 1
Tube Outside Diameter (in) - A4 1.38
Top Width Per Strand (Millimeter) .05
Gasket Quantity 0
Seal Quantity 1
Material Stainless Steel, Copper
Type Premium Thermostat
Hazardous Material No
Item Level GTIN 00770075745341
Minimum Order Quantity 1
Quantity Per Application 1
Country of Origin United States
Weight - Each (Gross Pounds) 0.2000
Weight - Case (Gross Pounds) 4.1000
Height - Each (Inch) 2.7500
Height - Case (Inch) 3.8750
Make ModelYearEngineType
GMC ACADIA13-07V6-3.6LEngine Coolant Thermostat
GMC CANYON16-15V6-3.6LEngine Coolant Thermostat
GMC TERRAIN12-10V6-3.0LEngine Coolant Thermostat
GMC TERRAIN2013V6-3.6LEngine Coolant Thermostat
PONTIAC TORRENT09-08V6-3.6LEngine Coolant Thermostat
